What are the uses for Lubricants?
A lubricant is a substance introduced to reduce friction between moving surfaces. It may also have the function of transporting foreign particles. The property of reducing friction is known as lubricity. (Slipperiness)
A good lubricant possesses the following characteristics:
- High boiling point
- Low freezing point
- High viscosity index
- Thermal stability
- Hydraulic Stability
- Demulsibility
- Corrosion prevention
- High resistance to oxidation
One of the single largest applications for lubricants, in the form of motor oil, is protecting the internal combustion engines in motor vehicles and powered equipment.
Typically lubricants contain 90% base oil (most often petroleum fractions, called mineral oils) and less than 10% additives. Vegetable oils or synthetic liquids such as hydrogenated polyolefins, esters, silicones, fluorocarbons and many others are sometimes used as base oils. Additives deliver reduced friction and wear, increased viscosity, improved viscosity index, resistance to corrosion and oxidation, aging or contamination, etc.
Lubricants such as 2-cycle oil are added to fuels like gasoline which has low lubricity. Sulfur impurities in fuels also provide some lubrication properties, which has to be taken in account when switching to a low-sulfur diesel; biodiesel is a popular diesel fuel additive providing additional lubricity.
Non-liquid lubricants include grease, powders (dry graphite, PTFE, Molybdenum disulfide, tungsten disulfide, etc.), PTFE tape used in plumbing, air cushion and others. Dry lubricants such as graphite, molybdenum disulfide and tungsten disulfide also offer lubrication at temperatures (up to 350 °C) higher than liquid and oil-based lubricants are able to operate. Limited interest has been shown in low friction properties of compacted oxide glaze layers formed at several hundred degrees Celsius in metallic sliding systems, however, practical use is still many years away due to their physically unstable nature.
Another approach to reducing friction and wear is to use bearings such as ball bearings, roller bearings or air bearings, which in turn require internal lubrication themselves, or to use sound, in the case of acoustic lubrication.
Keep moving parts apart
Lubricants are typically used to separate moving parts in a system. This has the benefit of reducing friction and surface fatigue, together with reduced heat generation, operating noise and vibrations. Lubricants achieve this by several ways. The most common is by forming a physical barrier i.e., a thin layer of lubricant separates the moving parts. This is analogous to hydroplaning, the loss of friction observed when a car tire is separated from the road surface by moving through standing water. This is termed hydrodynamic lubrication. In cases of high surface pressures or temperatures, the fluid film is much thinner and some of the forces are transmitted between the surfaces through the lubricant.
Reduce friction
Typically the lubricant-to-surface friction is much less than surface-to-surface friction in a system without any lubrication. Thus use of a lubricant reduces the overall system friction. Reduced friction has the benefit of reducing heat generation and reduced formation of wear particles as well as improved efficiency. Lubricants may contain additives known as friction modifiers that chemically bind to metal surfaces to reduce surface friction even when there is insufficient bulk lubricant present for hydrodynamic lubrication, e.g. protecting the valve train in a car engine at startup.
Transfer heat
Both gas and liquid lubricants can transfer heat. However, liquid lubricants are much more effective on account of their high specific heat capacity. Typically the liquid lubricant is constantly circulated to and from a cooler part of the system, although lubricants may be used to warm as well as to cool when a regulated temperature is required. This circulating flow also determines the amount of heat that is carried away in any given unit of time. High flow systems can carry away a lot of heat and have the additional benefit of reducing the thermal stress on the lubricant. Thus lower cost liquid lubricants may be used. The primary drawback is that high flows typically require larger sumps and bigger cooling units. A secondary drawback is that a high flow system that relies on the flow rate to protect the lubricant from thermal stress is susceptible to catastrophic failure during sudden system shut downs. An automotive oil-cooled turbocharger is a typical example. Turbochargers get red hot during operation and the oil that is cooling them only survives as its residence time in the system is very short i.e. high flow rate. If the system is shut down suddenly (pulling into a service area after a high speed drive and stopping the engine) the oil that is in the turbo charger immediately oxidizes and will clog the oil ways with deposits. Over time these deposits can completely block the oil ways, reducing the cooling with the result that the turbo charger experiences total failure typically with seized bearings. Non-flowing lubricants such as greases & pastes are not effective at heat transfer although they do contribute by reducing the generation of heat in the first place.
Carry away contaminants and debris
Lubricant circulation systems have the benefit of carrying away internally generated debris and external contaminants that get introduced into the system to a filter where they can be removed. Lubricants for machines that regularly generate debris or contaminants such as automotive engines typically contain detergent and dispersant additives to assist in debris and contaminant transport to the filter and removal. Over time the filter will get clogged and require cleaning or replacement, hence the recommendation to change a car's oil filter at the same time as changing the oil. In closed systems such as gear boxes the filter may be supplemented by a magnet to attract any iron fines that get created.
It is apparent that in a circulatory system the oil will only be as clean as the filter can make it, thus it is unfortunate that there are no industry standards by which consumers can readily assess the filtering ability of various automotive filters. Poor filtration significantly reduces the life of the machine (engine) as well as making the system inefficient.
Transmit power
Main article: Hydraulics
Lubricants known as hydraulic fluid are used as the working fluid in hydrostatic power transmission. Hydraulic fluids comprise a large portion of all lubricants produced in the world. The automatic transmission's torque converter is another important application for power transmission with lubricants.
Protect against wear
Lubricants prevent wear by keeping the moving parts apart. Lubricants may also contain anti-wear or extreme pressure additives to boost their performance against wear and fatigue.
Prevent corrosion
Good quality lubricants are typically formulated with additives that form chemical bonds with surfaces, or exclude moisture, to prevent corrosion and rust.
Seal for gases
Lubricants will occupy the clearance between moving parts through the capillary force, thus sealing the clearance. This effect can be used to seal pistons and shafts.
